High Refresh Rate
Diodes Lifespan
Seamless Alignment
Engineered feature supporting international for peak operational performance.
Engineered feature supporting low consumption for peak operational performance.
Engineered feature supporting super light for peak operational performance.
Transforming conventional environments into dynamic high-resolution digital hubs.
Engineered feature supporting high resistance cabinet for peak operational performance.
Engineered feature supporting indoor/outdoot product for peak operational performance.
Engineered feature supporting spectacular colors for peak operational performance.
Tecnoled LED screens incorporate state-of-the-art SMD and MicroLED configurations to deliver unparalleled brightness, contrast, and color accuracy. Engineered with modular aluminum cabinets, these displays utilize advanced control systems to ensure seamless pixel alignment, real-time synchronization, and refresh rates up to 3840Hz. The high-density diode design ensures crystal-clear visual performance in both indoor corporate environments and high-exposure outdoor settings.
Designed to satisfy versatile structural requirements. This model is widely integrated across multiple fields:
| ITEM | Linsn | 3.91-7.82 | 7.82-7.82 | 10.4-10.4 |
|---|---|---|---|---|
| LED Type | N/A | 1R1G1B | 1R1G1B | 1R1G1B |
| Pixel Pitch | mm | 3.91-7.82 | 7.82-7.82 | 10.4-10.4 |
| Ingress Protection | IP | IP45 | ||
| Viewing Distance | meter | 5-100 | 8-100 | 15-120 |
| Transparency | N/A | 0.8 | 0.8 | 0.85 |
| Module Dimension | mm | 500*500 500*1000 | 500*500 500*1000 | 500*500 500*1000 |
| Weight | KG/㎡ | 15 | 15 | 14 |
| Thickness | cm | 8.5 | 8.5 | 8.5 |
| Brightness | Nits | 5500 | ||
| Refresh rate | Hz | ≥1920 | ||
| Viewing Angle | N/A | 120° | ||
| Gray Scale | Level | 14bits | ||
| AC Speration | V | AC90~264 | ||
| Power Consumption(Max/Avg) | W/m2 | 800/240 ( Estimate ) | ||
| Storage Tem. | F/C | -4 ~ 140F/-20C ~ +60C | ||
| Storage Humidity | RH | 10% ~ 85% | ||
| Operating Tem. | F/C | -4F ~ 140F/-20C ~ +60 | ||
| Operating Humidity | RH | 10% ~ 85% | ||
| Lift time(50% brightness) | Hour | 100,000 | ||
| Control Mode | N/A | Video Sync |
Submit details to get direct engineer response, structural calculation advising, or customized dimensions pricing.
